High Precision Rolled Copper Foil
Inquiry
Product introduction
Lamination metal foil is a high precision, ultra-thin copper product with a thickness typically ranging from 4-100 microns and a width generally less than 800mm. It is made by the principle of plastic deformation processing, repeatedly rolling and annealing high precision copper strip. Lamination copper foil has excellent ductility, bendability, and conductivity, with a copper purity higher than that of electrolytic copper foil.
The product is mainly used for the production of printed circuit boards (PCB), copper clad laminates (CCL), and flexible copper clad laminates (FCCL), flexible printed circuits (FPC), 5G/6G communication, electromagnetic shielding, and heat dissipation substrates.
Physical Properties
| Grades | Sports event | Thicknesses | ||||
| 70 | 50 | 35 | 18 | |||
| C1100 | Grammage(g/m2) | 605±5 | 43±5 | 300±5 | 152±5 | |
| Tensile Strength | Before heat treatment | ≥410 | ≥410 | ≥410 | ≥410 | |
| After heat treatment | ≥190 | ≥ 190 | ≥180 | ≥160 | ||
| Elongation(%) | Before heat treatment | ≥1.2 | ≥1.2 | ≥1.2 | ≥1.2 | |
| After heat treatment | ≥20.0 | ≥15 | ≥12 | ≥10.0 | ||
| Surface roughness(μm) | Smooth | ≤0.15 | ≤0.15 | ≤0.15 | ≤0.15 | |
| Hair surface | ≤2.3 | ≤2.3 | ≤2.3 | ≤2.3 | ||
| Conductivity(%IACS) | ≥98 | ≥98 | ≥98 | ≥98 | ||
| Peel strength(g/cm) | ≥0.6 | ≥0.6 | ≥0.6 | ≥0.6 | ||
| Softening temperature CC) | ≥160 | ≥160 | ≥160 | ≥160 | ||
| High temperature oxidation resistance | 200°C/1h non-oxidising | |||||
Ingredient Content
Product parameters
Centred Services
Wenzhou Hongfeng Electrical Alloy Co., Ltd. (hereinafter referred to as “Wenzhou Hongfeng”), founded in September 1997. The main products include electrical contact materials, metal-matrix engineered composite materials, cemented carbide materials, high-performance extremely thin lithium copper foil, and intelligent equipment, providing customers with integrated functional solutions from material research and development to component manufacturing, and then intelligent manufacturing. As High Precision Rolled Copper Foil company in China, the products are widely applied in industrial manufacturing, intelligent transportation systems, smart homes, communication information, aerospace, mining, machinery manufacturing, medical, and other fields.From quotation to delivery, we provide one-stop customer service, respond quickly to customer needs, solve problems efficiently, and complete delivery; in addition, we can also provide professional material design, process optimization, sample preparation testing, mass production supply, and technical support through services such as professional material design, process optimization, and technical support. Meet customer needs for high-performance alloy materials.
-
Materials Design
And DevelopmentDesign and development of new alloy functional composite materials can be carried out according to customer needs and application requirements.
-
Manufacturing Process
OptimizationThe manufacturing process of new alloy functional composite materials can be optimized for customers.
-
Sample Preparation
And TestingWe can provide customers with sample preparation and testing services for new alloy functional composite materials.
-
Mass Production
And SupplyOnce the new alloy functional composite materials are mass-produced and provide stable and reliable supply.
-
Technical Support
And ConsultingHongfeng can also provide relevant technical support and consulting services to customers. High Precision Rolled Copper Foil Suppliers.
